Product Specifications
| Associated Standards | AS/NZS 4671:2001 Steel Reinforcing Materials |
| Welded Wire Reinforcement Can Be Used For |
★ Slab on Grade Reinforcement、Floor and Walls Systems.Topping Slabs.Architectural Precast ★ Wall Panels、Tilt-up Construction WallSystems.Shear Walls、Retaining walls ★ Mechanically Stabilized Earth(M.S.E.)Reinforcement |
| Code | Cross Wire In mm | Long Wire In mm | Mass/Sheet kg | Quantity /Container |
| SL81 | 7.6@100 | 7.6@100 | 105 | 238 |
| SL62 | 6.0@200 | 6.0@200 | 33 | 680 |
| SL72 | 6.75@200 | 6.75@200 | 41 | 588 |
| SL82 | 7.6@200 | 7.6@200 | 52 | 480 |
| SL92 | 8.55@200 | 8.55@200 | 65 | 390 |
| SL102 | 9.5@200 | 9.5@200 | 80 | 300 |
| Code | Cross Wire In mm | Long Wire In mm | Mass/Sheet kg | Quantity /Container |
| RL718 | 7.6@200 | 6.75@100 | 68 | 20 |
| RL818 | 7.6@200 | 7.6@100 | 79 | 20 |
| RL918 | 7.6@200 | 8.55@100 | 93 | 20 |
| RL1018 | 7.6@200 | 9.5@100 | 109 | 15 |
| RL1118 | 7.6@200 | 10.65@100 | 131 | 15 |
| RL1218 | 7.6@200 | 11.9@100 | 157 | 10 |
| 68 Mesh | Sheet Size | Wire Size | Sheet Weight | Centre Width |
| 668 Standard | 4510x1960mm | 4mm | 12.22kg | 150mm Centres |
| 668 Large | 5870x2120mm | 4mm | 17.06kg | 150mm Centres |
| 661 Mesh | Sheet Size | Wire Size | Sheet Weight | Centre Width |
| 661 Large | 4510x1960mm | 7.5mm | 59.99kg | 150mm Centres |
| 661 Standard | 5870x2120mm | 7.5mm | 37.82kg | 150mm Centres |
| 665 Mesh | Sheet Size | Wire Size | Sheet Weight | Centre Width |
| 665 Standard | 4510x1960mm | 5.3mm | 21.46kg | 150mm Centres |
| 665 Large | 5870x2120mm | 5.3mm | 29.95kg | 150mm Centres |
